DES-1218R/DES-1226R 10/100/1000 Mbps Ethernet Switch User’s Guide

Switching Technology

Another key development pushing the limits of Ethernet technology is in the field of switching

technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol

transmitting among connected Ethernet or fast Ethernet LAN segments.

Switching is a cost-effective way of increasing the total network capacity available to users on a local

area network. A switch increases capacity and decreases network loading by making it possible for a

local area network to be divided into different segments which don’t compete with each other for

network transmission capacity, giving a decreased load on each.

The switch acts as a high-speed selective bridge between the individual segments. Traffic that needs

to go from one segment to another (from one port to another) is automatically forwarded by the

switch, without interfering with any other segments (ports). This allows the total network capacity

to be multiplied, while still maintaining the same network cabling and adapter cards.

For Fast Ethernet or Gigabit Ethernet networks, a switch is an effective way of eliminating

problems of chaining hubs beyond the “two-repeater limit.” A switch can be used to split parts of the

network into different collision domains, for example, making it possible to expand your Fast

Ethernet network beyond the 205-meter network diameter limit for 100BASE-TX networks.

Switches supporting both traditional 10Mbps Ethernet and 100Mbps Fast Ethernet are also ideal for

bridging between existing 10Mbps networks and new 100Mbps networks.

Switching LAN technology is a marked improvement over the previous generation of network

bridges, which were characterized by higher latencies. Routers have also been used to segment local

area networks, but the cost of a router and the setup and maintenance required make routers

relatively impractical. Today’s switches are an ideal solution to most kinds of local area network

congestion problems.

DES-1218R/DES-1226R 10/100/1000 Mbps Switch

General Description of Switch

The Switch is equipped with unshielded twisted-pair (UTP) cable ports providing dedicated 10 or 100

Mbps bandwidth. The DES-1218R has 16 UTP ports and the DES-1226R has 24 UTP ports. Each

model includes 16 or 24 MDI-X/MDI-II convertible ports that can be used for uplinking to another

switch. These ports can be used for connecting PCs, servers, and hubs. The dual speed ports use

standard twisted-pair cabling and are ideal for segmenting networks into small, connected

subnetworks. Each port can support up to 200 Mbps of throughput in full-duplex mode.

In addition, the Switch can be fitted with either an optional 2-port Gigabit Ethernet module or a 1-

or 2-port 100BASE module. The Gigabit ports are ideal for a high-bandwidth link to a server or

network backbone.

The Gigabit Ethernet modules that can be installed include: DES-132G 2-port 1000BASE-SX (SC

type connector), DES-132GL 2-port 1000BASE-LX, DES-132GB 2-port GBIC, and DES-132T 2-port

1000BASE-T modules.

The 100BASE modules that can be installed include: DES-131FL 1-port 100BASE-FX (15Km), DES-

132FL 2-port 100BASE-FX (15Km), DES-131F 1-port 100BASE-FX (2Km), and DES-132F 2-port

100BASE-FX (2Km).

This stand-alone Switch enables the network to use some of the most demanding multimedia and

imaging applications concurrently with other user applications without creating bottlenecks. The

built-in console interface can be used to configure the Switch’s settings for priority queuing, VLANs,

and port trunk groups, port monitoring, and port speed.
