DES-1218R/DES-1226R 10/100/1000 Mbps Ethernet Switch User’s Guide
5
♦ Support Full-duplex operation only
♦ IEEE 802.3x compliant Flow Control support for full-duplex
100BASE-FX Module (DES-132FL) (15Km)
♦ Two 100BASE-FX (with SC type connector) ports
♦ Fully compliant with IEEE802.3u
♦ Support Full-duplex operation only
♦ IEEE 802.3x compliant Flow Control support for full-duplex
