DES-1218R/DES-1226R 10/100/1000 Mbps Ethernet Switch User’s Guide
4
Optional 2-Port Gigabit Extension Modules
1000BASE-SX (SC) Module (DES-132G)
♦ 1000BASE-SX (with SC type connector) Gigabit Ethernet ports
♦ Fully compliant with IEEE802.3z
♦ Support Auto-Negotiation and Force 1000-Full mode
♦ IEEE 802.3x compliant Flow Control support for full-duplex
1000BASE-LX (SC) Module (DES-132GL)
♦ 1000BASE-LX (with SC type connector) Gigabit Ethernet ports
♦ Fully compliant with IEEE802.3z
♦ Support Auto-Negotiation and Force 1000-Full mode
♦ IEEE 802.3x compliant Flow Control support for full-duplex
GBIC Gigabit Ethernet Module (DES-132GB)
♦ GBIC Gigabit Ethernet ports
♦ Support Auto-Negotiation and Force 1000-Full mode
♦ IEEE 802.3x compliant Flow Control support for full-duplex
Note: This module requires using a GBIC converter. Contact your D-Link vendor for either the
DGS-701 1000BASE-SX GBIC FTR-8519-3A (Finisar) or DGS-702 1000BASE-LX GBIC
FTR-1319-3A (Finisar).
1000BASE-T Module (DES-132T)
♦ 1000BASE-T Gigabit Ethernet ports
♦ Fully compliant with IEEE802.3ab
♦ Support NWay Auto-negotiation in all modes
♦ Support Auto-negotiation for flow-control
♦ IEEE 802.3x compliant Flow Control support for full-duplex
♦ Back pressure flow control support for half-duplex mode
Optional 100BASE Extension Modules
100BASE-FX Module (DES-131F) (2Km)
♦ One 100BASE-FX (with SC type connector) Fiber port
♦ Fully compliant with IEEE802.3u
♦ Support Full-duplex operation only
♦ IEEE 802.3x compliant Flow Control support for full-duplex
100BASE-FX Module (DES-132F) (2Km)
♦ Two 100BASE-FX (with SC type connector) Fiber ports
♦ Fully compliant with IEEE802.3u
♦ Support Full-duplex operation only
♦ IEEE 802.3x compliant Flow Control support for full-duplex
100BASE-FX Module (DES-131FL) (15Km)
♦ One 100BASE-FX (with SC type connector) port
♦ Fully compliant with IEEE802.3u
