DES-1218R/DES-1226R 10/100/1000 Mbps Ethernet Switch User’s Guide
11
♦ 10/100 Mbps On the upper right corner of each twisted pair port, this LED will light when
the connection speed is operating at 100 Mbps. An unlit LED indicates a connection speed of
10 Mbps.
♦ Link (Optional module) Steady green indicates valid link.
♦ Act (Optional module) Blinking green indicates activity on port.
