D-Link DGS-1016TL/DGS-1024TL Gigabit Ethernet Switch

SECTION 2

Installation

Package Contents

Before You Connect to the Network

Installing the Switch Without the Rack

Rack Installation

Power On

Package Contents

Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the

following items:

• One DGS-1016TL 16-Port or DGS-1024TL 24-Port 10/100/1000BASE-T Gigabit Ethernet Switch.

• Accessory pack: 2 mounting brackets and screws.

• Four rubber feet with adhesive backing.

• One AC power cord.

• This Manual.

If any item is missing or damaged, please contact your local D-Link reseller for replacement.

Before You Connect to the Network

The site where you install the Switch may greatly affect its performance. Please follow these guidelines for

setting up the Switch.

Install the Switch on a sturdy, level surface that can support at least 3 kg (6.6 lbs.) of weight. Do not

place heavy objects on the Switch.

•

The power outlet should be within 1.82 meters (6 feet) of the Switch.

Visually inspect the power cord and see that it is fully secured to the AC power port.

Make sure that there is proper heat dissipation from and adequate ventilation around the Switch. Leave at

least 10 cm (4 inches) of space at the front and rear of the Switch for ventilation.

Install the Switch in a fairly cool and dry place for the acceptable temperature and humidity operating

ranges.

Install the Switch in a site free from strong electromagnetic field generators (such as motors), vibration,

dust, and direct exposure to sunlight.

When installing the Switch on a level surface, attach the rubber feet to the bottom of the device. The

rubber feet cushion the Switch, protect the casing from scratches, and prevent it from scratching other

surfaces.

Installing the Switch Without the Rack

When installing the Switch on a desktop or shelf, the rubber feet included with the Switch should first be

attached. Attach these cushioning feet on the bottom at each corner of the device. Allow enough ventilation

space between the Switch and any other objects in the vicinity.
