D-Link DGS-1024D [19/32] Glossary

D-Link DGS-1016TL/DGS-1024TL Gigabit Ethernet Switch

Glossary

1000BASE-T – 1000Mbps Gigabit Ethernet implementation over Category 5 and Category 5e UTP cabling.

100BASE-TX – 100Mbps Ethernet implementation over Category 5 and Type 1 twisted pair cabling.

10BASE-T – The IEEE 802.3 specification for Ethernet over Unshielded Twisted Pair (UTP) cabling.

aging – The automatic removal of dynamic entries from the Switch Database which have timed-out and are

no longer valid.

ATM – Asynchronous Transfer Mode. A connection oriented transmission protocol based on fixed length

cells (packets). ATM is designed to carry a complete range of user traffic, including voice, data, and video

signals.

auto-negotiation – A feature on a port which allows it to advertise its capabilities for speed, duplex, and

flow control. When connected to an end station that also supports auto-negotiation, the link can self-detect

its optimum operating setup.

backbone – The part of a network used as the primary path for transporting traffic.

backbone port – A port that does not learn device addresses, and that receives all frames with an unknown

address. Backbone ports are normally used to connect the Switch to the backbone of your network. Note that

backbone ports were formerly known as designated downlink ports.

bandwidth – Information capacity, measured in bits per second, that a channel can transmit. The bandwidth

of Ethernet is 10Mbps and the bandwidth of Fast Ethernet is 100Mbps.

baud rate – The switching speed of a line. Also known as line speed between network segments.

BOOTP – The BOOTP protocol allows you to automatically map an IP address to a given MAC address

each time a device is started. In addition, the protocol can assign the subnet mask and default gateway to a

device.

bridge – A device that interconnects local or remote networks no matter what higher level protocols are

involved. Bridges form a single logical network, centralizing network administration.

broadcast – A message sent to all destination devices on the network.

broadcast storm – Multiple simultaneous broadcasts that typically absorb available network bandwidth and

can cause network failure.

console port – The port on the Switch accepting a terminal or modem connector. It changes the parallel

arrangement of data within computers to the serial form used on data transmission links. This port is most

often used for dedicated local management.

CSMA/CD – Channel access method used by Ethernet and IEEE 802.3 standards, in which devices transmit

only after finding the data channel clear for some period of time. When two devices transmit simultaneously,

a collision occurs and the colliding devices delay their retransmissions for a random amount of time.

data center switching – The point of aggregation within a corporate network where a switch provides high-

performance access to server farms, a high-speed backbone connection, and a control point for network

management and security.

Ethernet – A LAN specification developed jointly by Xerox, Intel, and Digital Equipment Corporation.

Ethernet networks operate at 10Mbps using CSMA/CD to run over cabling.

Fast Ethernet – 100Mbps technology based on the Ethernet/CD network access method.

Flow Control – (IEEE 802.3z) A means of holding packets back at the transmit port of the connected end

station. Prevents packet loss at a congested switch port.

Forwarding – The process of sending a packet toward its destination by an internetworking device.

full duplex – A system that allows packets to be transmitted and received at the same time and, in effect,

doubles the potential throughput of a link.

half duplex – A system that allows packets to be transmitted and received, but not at the same time.

Contrasts with full duplex.

IP address – Internet Protocol address. A unique identifier for a device attached to a network using TCP/IP.

The address is written as four octets separated with full-stops (periods), and is made up of a network section,

an optional subnet section and a host section.

IPX – Internetwork Packet Exchange. A protocol allowing communication in a NetWare network.
