772/773

Calibration Manual

Symbols

Table 1 refers to the symbols that are on the Meter or in this manual.

Table 1. Symbols

- Do not apply around, or remove from HAZARDOUS LIVE conductors.

W Dangerous. Important data. See Users Manual.

X Risk of Electrical Shock.

T Equipment protected by double or reinforced insulation.

M Battery

B Low Battery

P Confirms with relevant European Union directives.

F DC (Direct Current)

Do not dispose of this the product as unsorted municipal waste. Go to Fluke’s web site for

recycling data.

; Conforms to relevant Australian standards.

) Conforms to relevant Canadian and US standards.

Specifications

Electrical Specifications

DC Current Measurement

With Jaw

Ranges ...................................... 0-20.99 mA; 21-100 mA

Resolution.................................. 0.01 mA; 0.1 mA

Accuracy.................................... 0.2 % + 5 counts; 1 % + 5 counts

In Circuit

Range........................................0-24 mA

Resolution.................................. 0.01 mA

Accuracy.................................... 0.2 % + 2 counts

Current Source

Range........................................0-24 mA

Resolution.................................. 0.01 mA

Accuracy.................................... 0.2 % + 2 counts

mA Drive.................................... 24 mA into 1000 Ω

Current Simulate

Range........................................0-24 mA

Resolution.................................. 0.01 mA

Accuracy.................................... 0.2 % + 2 counts

Maximum Voltage......................50 V

DC Voltage Measurement (773)

Range........................................0-30 V

Resolution.................................. 0.01 V

Accuracy.................................... 0.2 % + 2 counts
