772/773
Calibration Manual
12
Table 4 shows the Meter buttons you use to adjust the Meters calibration.
Table 4. Calibration Adjustments
Button Calibration Adjustment Description
Q
A short button push (1 second) changes the Meter to the first calibration step
A long button push exits the Meters calibration mode
D
G
Adjust source output in large steps
E
F
Adjust source output in small steps
H Forward to subsequent calibration step
The Meter display shows the value in each adjustment step.
• In Measure mode, the shown value is the calibrator input.
• In Source mode, the shown value is the Meter output.
To exit Calibration mode:
Push the calibration button a second time to keep new calibration constants and exit
calibration mode.
Calibration Error Messages
The calibration error messages that the Meter can show are in Table 5. Steps to remove
the messages are also shown in the table.
Table 5. Error Messages
Error Message Cause of Error Removal Steps
Cal Meter not calibrated, use default parameter Do all adjustments
Err Code area checksum error Meter repair is necessary
