11 Fluke Corporation 750 Series Brochure
Model Parameter/Range
Hi Side
Media
2
Lo Side
Media
2
Reference
Uncertainty
4
Total Uncertainty
1-year (15-35 �C)
Total Uncertainty
1-year
1
Total Uncertainty
6-month (15-35 �C)
Vacuum
750PV3 -5 psi (-350 mBar) 316 SS Dry Air ± 0.03
% ± 0.06
% ± 0.07
% ± 0.05
%
750PV4 -15 psi (-1 bar) 316 SS Dry Air ± 0.03
% ± 0.06
% ± 0.07
% ± 0.05
%
Dual
750PD2 -1 to 1 psi (-70 to 70 mBar) 316 SS Dry Air ± 0.05
% ± 0.1
% ± 0.15
% ± 0.075
%
750PD3 -5 to 5 psi (-350 to 350 mBar) 316 SS Dry Air ± 0.03
% ± 0.06
% ± 0.07
% ± 0.05
%
750PD10 -10 to 10 psi (-700 to 700 mBar) 316 SS Dry Air ± 0.025
% ± 0.05
% ± 0.07
% ± 0.04
%
750PD4 -15 to 15 psi (-1 to 1 bar) 316 SS Dry Air ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
750PD5 -15 to 30 psi (-1 to 2 bar) 316 SS N/A ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
750PD50 -15 to 50 psi (-1 to 3.5 bar) 316 SS N/A ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
750PD6 -15 to 100 psi (-1 to 7 bar) 316 SS N/A ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
750PD7 -15 to 200 psi (-1 to 14 bar) 316 SS N/A ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
750PD27 -15 to 300 psi (-1 to 20 bar) 316 SS N/A ± 0.0175
% ± 0.035
% ± 0.045
% ± 0.03
%
Reference
750R04
5
0 to 15 psi (0 to 1 bar) Dry Air Dry Air ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R06
5
0 to 100 psi (0 to 7 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R27 0 to 300 psi (0 to 20 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R07 0 to 500 psi (0 to 35 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R08
5
0 to 1000 psi (0 to 70 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R29 0 to 3000 psi (0 to 200 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R30 0 to 5000 psi (0 to 340 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750R31
5
0 to 10000 psi (0 to 700 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750RD5 -15 to 30 psi (-1 to 2 bar) Dry Air N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750RD6
5
-12 to 100 psi (-1 to 7 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
750RD27 -12 to 300 psi (-0.8 to 20 bar) 316 SS N/A ± 0.01
% of FS ± 0.02
% of FS ± 0.04
% of FS ± 0.015
% of FS
1. Total uncertainty, % of full span for temperature range 0 °C to +50 °C, one year interval. Total uncertainty, 1.0 % of full span for temperature range
-10 °C to 0°C, one year interval. No 6 month specification available for range -10 °C to 0 °C.
2. “NONCORROSIVE GASSES” indicates dry air or non-corrosive gas as compatible media. “Stainless Steel 316-SS” indicates media compatible with Type 316
Stainless Steel.
3. Specifications % of Full Span unless otherwise noted.
4. Reference Uncertainty is the specification for as left data for 24 hours.
5. When reference class modules are used with fixed resolution products (717, 718, 719 series, 725 and 726) calibrators add ± 1 count to the overall accuracy
specification.
6. Intrinsically Safe pressure module available in this pressure range.
Pressure module specifications (cont.) (all specifications in % of full span. Specifications reflect a confidence interval of 95 %.)
