![Fluke 754 [12/12] General specifications](/views2/1436073/page12/bgc.png)
General specifications
FLUKE-753 Documenting Process Calibrator
FLUKE-754 Documenting Process Calibrator-HART
Standard accessories include: Three sets of stackable
test leads, three sets of TP220 test probes with three
sets of “extended tooth” alligator clips, two sets AC280
hook clips, BP7240 Li-ion battery pack, BC7240 battery
charger, C799 field soft case, USB communication cable,
getting started guide, instruction manual, and instruc-
tion videos on CDROM, traceable certificate of calibra-
tion, DPC/TRACK 2 sample software that enables upload
and printing of calibration records. Model Fluke-754
includes HART communication cable. Includes C799
Field Soft Case. Includes three year warranty.
FLUKE-750SW DPC/TRACK 2 Software
Included with DPC/TRACK software:
Software media, Instruction Manual, USB Cable.
FLUKE-750 Pxx Pressure Modules
Included with each Fluke Pressure Module:
BP-ISO, M20 and 1/4 in NPT Adapter(s), Instruction
Sheet, traceable calibration report and data,
one-year warranty.
Accessories
Fluke-700PMP Pressure Pump; 100 psi/7 bar
Fluke-700LTP-1 Low Pressure Test Pump
Fluke-700PTP-1 Pneumatic Test Pump;
400 psi/40 bar
Fluke-700HTP-2 Hydraulic Test Pump;
10,000 psi/700 bar
Fluke-700HTH-1 Hydraulic Test Hose
Fluke-700PRV-1 Pressure Relief Valve Kit for HTP
Fluke-700-IV Current Shunt (for mA/mA
applications)
Fluke-700PCK Pressure Calibration Kit
Fluke-700TC1 TC Mini-Plug Kit, 9 types
Fluke-700TC2 TC Mini-Plug Kit, JKTERS
Fluke-700TLK Process Test lead kit
754HCC Smart instrument
communication cable
BC7240 Battery Charger
BP7240 Li-on Battery Pack
C700 Hard Carrying Case
C781 Soft Carrying Case
C799 Soft Field Case
Ordering information
Data log function
Measure functions: Voltage, current, resistance,
frequency, temperature, pressure
Reading rate: 1, 2, 5, 10, 20, 30, or 60 readings
per minute
Maximum record length: 8000 readings
(7980 for 30 or 60 readings per minute)
Ramp function
Source functions: Voltage, current, resistance,
frequency, temperature
Rate: 4 steps/second
Trip detect: Continuity* or voltage
*Continuity detection not available when sourcing current
Loop power function
Voltage: 26 V
Accuracy: 10 %, 18 V minimum at 22 mA
Maximum current: 25 mA, short-circuit protected
Maximum input voltage: 50 V dc
Note: 250 Ω series resistance is automatically supplied whenever loop power is
enabled on 754.
HART modem interface (754 only)
Maximum input voltage: 30 V dc
Environmental specifications
All calibrator specifications apply from +18 °C to
+28 °C unless stated otherwise.
Operating temperature: -10 °C to 50 °C
Storage temperature: -20 °C to 60 °C
Operating altitude: 3000 m above mean sea level
(9842 ft)
90-day specifications: The standard specification
intervals for the 750 Series are 1 and 2 years.
Typical 90-day measurement and source accuracy can
be estimated by dividing the one year “% of reading”
or “% of output” specifications by 2. Floor specifications,
expressed as “% of f.s.” or “counts” or “ohms” remain
constant.
Ingress protection:
IP-52
Power: Internal battery pack li-ion, 7.2 V, 4400 mAh,
30 Wh; Battery life: Typical usage, >8 hours
Dimensions: 136mm x 245mm x 63 mm
(5.4 in x 9.6 in x 2.5 in)
Weight: 1.2 kg (2.7 lb)
Side port connections:
• Pressure module connector
• USB connector to interface to your PC
• Digital instrument (HART) connector
• Connection for optional battery charger/eliminator
Safety: Complies with CAN/CSA C22.2 No 1010.1-92,
ANSI/ISA S82.01-1994, UL3111, and EN610-1:1993.
Data storage capacity:
1 week of calibration procedures and results
12 Fluke Corporation 750 Series Brochure
Fluke Corporation
PO Box 9090,
Everett, WA 98206 U.S.A.
Fluke. Keeping your world up and running.
®
For more information call:
In the U.S.A. (800) 443-5853 or Fax (425) 446-5116
In Europe/M-East/Africa +31 (0)40 267 5100 or Fax +31 (0)40 267 5222
In Canada (800)-36-FLUKE or Fax (905) 890-6866
From other countries +1 (425) 446-5500 or Fax +1 (425) 446-5116
Web access: http://www.fluke.com
©2004-2013, 2015 Fluke Corporation. Specifications subject to change without notice.
Printed in U.S.A. 11/2015 1263323o-en
