D-Link DWL-2000AP+ [5/53] Connections
![D-Link DWL-2000AP+ [5/53] Connections](/views2/1044289/page5/bg5.png)
5
Connections
The LAN Port is
Auto-MDI/MDIX. You
can insert either a
Straight-through or
a Cross-over
Ethernet cable in
this port in order to
connect the DWL-
2000AP+ to a
switch on the local
network.
Receptor
for the
Power
Adapter
Pressing the
Reset Button
restores the
router to its
original factory
default settings.
