26D-Link DIR-645 User Manual

Section 3 - Software Conguration

Address Mode: Here the user can specify whether this Internet

connection requires the use of a Dynamic or

Static IP address. L2TP usual requires a Dynamic IP

conguration.

L2TP IP Address: Enter the L2TP IP address used here. This option is

only available if Static IP is selected.

L2TP Subnet

Mask:

Enter the L2TP Subnet Mask used here.

L2TP Gateway IP

Address:

Enter the L2TP Gateway IP address used here.

L2TP Server IP

Address:

Enter the L2TP Server IP address used here. This is

normally the same a the L2TP Gateway IP address.

Username: Enter the L2TP username used here.

Password: Enter the L2TP password used here.

Verify Password: Re-enter the L2TP password used here.

Reconnect

Mode:

Use the radio buttons to specify the reconnect

mode. The user can specify a custom schedule

or specify the On Demand, or Manual option. To

specify a custom schedule, use the drop-down

menu to select one of the schedules that has been

dened in the Schedules page. To create a new

schedule, click the New Schedule button to open

the Schedules page. Schedules will be discussed

later.

Maximum Idle

Time:

Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this feature,

enable Auto-reconnect.

Primary DNS

Server:

Enter the Primary DNS IP address used here.

Secondary DNS

Server:

Enter the Secondary DNS IP address used here. This eld is normally optional. Only one DNS address is required for a functional

Internet connection, but using a second DNS address provides more stability.
