5
Controls
Button Function Led
A
Motor off. The Leds indicating the Speed of the motor turn off.
Enables / Disables Keyboard Lock mode if pressed and held
for 5 seconds.
All the Leds light up in cycle and run a start-up sequence.
B
Activates speed one. The Leds indicating Speed one and Motor Off turn on.
C
Activates speed two. The Leds indicating Speed two and Motor Off turn on.
D
Activates speed three. The Leds indicating Speed three and Motor Off turn on.
Press and hold the button for approximately 5 seconds,
with all the loads turned off (Motor and Lights), to turn the
Activated Charcoal Filter alarm on.
To turn it off, press and hold the button again for 5 seconds.
ButtonA LED ashes twice.
ButtonA LED ashes once.
E
Activates speed four. The Leds indicating Speed four and Motor Off turn on.
Press and hold for 5 sec. to activate Intensive speed. This speed
is timed to run for 6 minutes. At the end of this time the system
will return to the speed set previously.
It is disabled by pressing the Button or turning the Motor off.
The Led ashes once a second and button A Led
lights up.
F
Starts the 24H function, in which the motor starts at a speed that
allows suction of 100 m3/h for 10 minutes per hour. This mode
cannot be activated if Intensive or Delay modes are active.
To deactivate it, press the same button or button A.
The Leds indicating 24H speed and Motor Off turn on.
24H Led Flashing:
Indicates the need to wash the metal grease lters. The
alarm is triggered after the Hood has been in operation
for 100 working hours.
When the lters alarm is triggered, the alarm can be reset by
pressing and holding this button for approximately 5 seconds.
These indications are only visible when the motor is turned off.
The buttonA Led ashes three times
G
Activates Delay mode, causing automatic shutdown of the Motor
and the Lighting system with a 20’ delay.
It is disabled by pressing the button or turning the motor off.
The Delay and Motor Off button Leds turn on.
Delay Led Flashing:
Indicatestheneedtochangetheactivatedcharcoallters,
and also to wash the metal grease lters. The alarm is
triggered after the Hood has been in operation for 200
working hours.
Pressing and holding the button for 5 seconds enables the
remote control.
Pressing and holding the button for 5 seconds disables the
remote control
ButtonA Led ashes twice.
ButtonA Led ashes once.
H
Press briey to turn the lighting system on and off at maximum
intensity.
The Led on the button lights up.
Press and hold the button for 2 seconds to turn the Courtesy
Lights On (if provided).
The Led on the button lights up.
Lighting
• For replacement contact technical
support (“To purchase contact
technical support”).
