13
Immediately after power-up, all of the LED’s should show steady
green for several seconds. Then the LPT1, LPT2, and LPT3 LEDs
should flash on simultaneously three times. Irregularity of any of the
three LEDs during these LED tests may mean there is a problem with
the LEDs themselves. Contact your dealer for correction of any LED
problems before proceeding.
The actual component tests immediately follow the LED tests. A
normal (no fault) result is signaled by a series of three cycles of
sequential flashing of the three LEDs, followed by a quiescent state
with all three LEDs dark.
If the self-test routine traps any component error, then following the
LED tests the self-test will halt and the LED’s will continuously signal
the error according to the following table. In the event of any such
error signal, contact your dealer for correction of the faulty unit.
LED Name
Faulty
LPT1 LPT2 LPT3
Component
Off off on/steady LPT3 error
Off off flashing Parallel-3 Controller error
Off on/steady off LPT2 error
Off flashing off
Parallel-2 Controller error
Off flashing flashing Flash Protected
on/steady off off LPT1 error
on/steady off on/steady Timer INT error
on/steady on/steady off RAM error
Flashing off off Parallel-1 Controller error
Flashing flashing off Flash erase/program error
Flashing flashing flashing Need to reload firmware
