12
The print server supports two infrastructure operations (‘Cfg ESS-ID
mode and ‘Any ESS-ID’ mode).
‘Cfg ESS-ID’ mode: The print server will connect to the access
point that have the same ESS-ID with the print server’s configured
ESS-ID.
‘Any ESS-ID’ mode: The print server will connect to any access
point that print server finds first, however, the ESS-ID may not be the
same with each other. This is an easier way to connect to the access
point if you only have one access point, but be careful, it may connect
to your neighbor’s access point.
5. While each printer is powered off, install a printer cable to
connect its parallel port to the printer port of the Print Server.
6. Switch “ON” each connected printer.
7. Plug the AC power adapter’s DC output plug into the DC 5V
power socket on the rear panel of the Print Server.
8. Plug the power adapter into an electric service outlet. This will
supply power to the Print Server, as it has no external power
switch. The Power LED on the Print Server’s front panel
should light steady green, and the Print Server’s self-test will
proceed.
Power On Self-Test
When the Print Server is powered on, it automatically performs a self-
test on each of its major components. The final result of the self-test
is signaled by the state of the LPT1, LPT2, and LPT3 LED indicators
following the self-test. Preliminary to the actual component tests, the
three LED indicators are tested to confirm their steady and flashing
operation.
