Cfg ESS-ID (Configured ESS-ID)
• Connect to Access Point with ESS-ID
• Default ESS-ID is ‘default’
Any ESS-ID
• Connect to Access Point with any ESS-ID closest to the unit
Reset Button
Reset of the unit will be initiated when the reset button is pressed
once and then LEDs on LPT1, LPT2 & LPT3 begins to flash.
Factory Reset will be initiated when the reset button is pressed for
three seconds or when the LEDs on LPT1, LPT2 & LPT3 begins to
light up solid. Release the reset button and LPT1, LPT2, & LPT3
LEDs will begin to flash indicating the print server is changing to
factory reset. When factory reset is completed the print server’s
wireless setting will be set to default on channel 6 and ESS-ID is set as
‘default’.
DC Power Connector
The DC power input connector is located on the Print Server’s rear
panel and is labeled DC 5V.
LED Indicators
The front panel of the Print Server features several LED indicators:
Front Panel LED Indicators
