D-Link DSA-3100 [10/76] Requirements
![D-Link DSA-3100 [10/76] Requirements](/views2/1044935/page10/bga.png)
10
Installation
Standard 10/100Base-T network (UTP/Cat5 Ethernet) cable
with RJ45 connectors.
TCP/IP network protocol must be installed on all networked
computers and related devices.
Requirements
