![D-Link DSA-3100 [51/76] Using the configuration utility continued](/views2/1044935/page51/bg33.png)
51
Using the Configuration Utility (continued)
Status > Device Info (continued)
Current Firmware Version Displays the current firmware version
System Name System name; DSA-3100 is the default
Admin Detail Information about the admin
Succeed Page The URL that appears after a successful user
login–usually a corporation’s homepage
External Syslog Server Shows the IP address and the Port of the
Syslog server
Console Port Baud Rate 9600bps
Manage SSH The IP address that connects to the WAN port
for configuring the DSA-3100
History Retain Days The system will keep user login information
for 3 days
E-mail to E-mails the traffic history file to this address
Time External Time Server Used for clock synchronization
Date Time Displays Greenwich time
User Idle Logout Timer 10 Min(s)
Multiple Login When disabled, it disallows a single user from
logging in multiple times
User Type Displays the user account authentication
method
Guest Account Displays guest account status
DNS Preferred DNS server DNS server IP address (Primary).
Alternate DNS server DNS server IP address (Secondary).
