- 39 - BIOS Setup
2-3 MB Intelligent Tweaker(M.I.T.)
• Whether the system will work stably with the overclock/overvoltage settings you made is depen-
dent on your overall system congurations. Incorrectly doing overclock/overvoltage may result in
damage to CPU, chipset, or memory and reduce the useful life of these components. This page is
for advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
• When the System Voltage Optimized item blinks in red, it is recommended that you set the
System Voltage Control item to Auto to optimize the system voltage settings.
(Note) This item appears only if you install a CPU that supports this feature.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
MB Intelligent Tweaker(M.I.T.)
Advanced Clock Calibration
(Note)
[Press Enter]
HT Link Frequency [Auto]
CPU Clock Ratio [Auto]
CPU NorthBridge Freq.
(Note)
[Auto]
CPU Host Clock Control [Auto]
x CPU Frequency(MHz) 200
PCIE Clock(MHz) [Auto]
VGA Core Clock control [Disabled]
x VGA Core Clock(MHz) 500
Set Memory Clock [Auto]
x Memory Clock x4.00 800Mhz
DCTs Mode
(Note)
[Unganged]
DRAMConguration [PressEnter]
********
System Voltage Optimized
********
System Voltage Control [Manual]
DDR2 Voltage Control [Normal]
NorthBridge Volt Control [Normal]
SouthBridge Volt Control [Normal]
SidePort Mem Volt Control [Normal]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
MB Intelligent Tweaker(M.I.T.)
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CPU NB VID Control
(Note)
[Normal]
CPU Voltage Control [Normal]
Normal CPU Vcore 1.3250V
