- 43 - BIOS Setup

Precharge Time

Options are: Auto (default), 2T, 3T.

Row Cycle Time

Options are: Auto (default), 11T~26T.

RAS to RAS Delay

Options are: Auto (default), 2T~5T.

(Note) This item appears only if you install a CPU that supports this feature.

********

System Voltage Optimized

********

System Voltage Control

Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the

system voltages as required. Manual allows all voltage control items below to be congurable. (Default:

Manual)

DDR2 Voltage Control

Allows you to set memory voltage.

Normal Supplies the memory voltage as required. (Default)

+0.1V ~ +0.3V Increases memory voltage by 0.1V to 0.3V at 0.1V increment.

Note: Increasing memory voltage may result in damage to the memory.

NorthBridge Volt Control

Allows you to set the North Bridge voltage.

Normal Supplies the North Bridge voltage as required. (Default)

+0.1V ~ +0.3V Increases North Bridge voltage by 0.1V to 0.3V at 0.1V increment.

SouthBridge Volt Control

Allows you to set the South Bridge voltage.

Normal Supplies the South Bridge voltage as required. (Default)

+0.1V ~ +0.3V Increases South Bridge voltage by 0.1V to 0.3V at 0.1V increment.

SidePort Mem Volt Control

Allows you to set the SidePort memory voltage.

Normal Supplies the SidePort memory voltage as required. (Default)

+0.1V ~ +0.3V Increases SidePort memory voltage by 0.1V to 0.3V at 0.1V increment.

CPU NB VID Control

(Note)

Allows you to set the CPU Northbridge VID voltage. Auto sets the CPU Northbridge VID voltage as re-

quired. The adjustable range is dependent on the CPU being installed. (Default: Normal)

Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.

CPU Voltage Control

Allows you to set the CPU voltage. Auto sets the CPU voltage as required. The adjustable range is de-

pendent on the CPU being installed. (Default: Normal)

Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.

Normal CPU Vcore

Displays the normal operating voltage of your CPU
