- 7 -

GA-MA785GPM-UD2H/GA-MA785GM-UD2H(US2H)

Motherboard Layout

"*" The GA-MA785GPM-UD2H/GA-MA785GM-UD2H adopts All-Solid Capacitor design.

Only for GA-MA785GPM-UD2H.

(Note) Use this port to connect a PS/2 keyboard or PS/2 mouse.

(Note)

_USB

CPU_FAN

Socket AM2

ATX

GA-MA785GPM-UD2H/

GA-MA785GM-UD2H/

GA-MA785GM-US2H

CD_IN

F_AUDIO

AUDIO

SPDIF_IO

PCIEX1

IDE

PWR_LED

DDR2_1

DDR2_2

ATX_12V_2X4

AMD 785G

AMD SB710

SATA2_3

SATA2_0

SATA2_4

SATA2_2

SATA2_1

PCI1

DVI

VGA

CODEC

OPTICAL

HDMI

USB

LAN

PCI2

CLR_CMOS

BATTERY

M_BIOS

FDD

F_PANEL

COM

RTL8111C

B_BIOS

IT8718

TSB43AB23

SYS_FAN

PCIEX16

ESATA

1394

USB

NB_FAN

F_1394_1

F_USB1

F_USB2

F_USB3

SidePort Memory

DDR2_3

DDR2_4

LPT
