Gigabyte GA-MA785GPM-UD2H (rev.1.0) [42/104] Dram configuration
![Gigabyte GA-MA785GPM-UD2H (rev.1.0) [42/104] Dram configuration](/views2/1045082/page42/bg2a.png)
BIOS Setup - 42 -
DDRII Timing Items
Manual allows all DDR2 Timing items below to be congurable.
Options are: Auto (default), Manual.
CAS# latency
Options are: Auto (default), 3T~6T.
RAS to CAS R/W Delay
Options are: Auto (default), 3T~6T.
Row Precharge Time
Options are: Auto (default), 3T~6T.
Minimum RAS Active Time
Options are: Auto (default), 5T~18T.
1T/2T Command Timing
Options are: Auto (default), 1T, 2T.
TwTr Command Delay
Options are: Auto (default), 1T~3T.
Trfc0 for DIMM1
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
Trfc2 for DIMM2
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
Trfc1 for DIMM3
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
Trfc3 for DIMM4
Options are: Auto (default), 75ns, 105ns, 127.5ns, 195ns, 327.5ns.
Write Recovery Time
Options are: Auto (default), 3T~6T.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
DRAMConguration
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
DDRII Timing Items [Auto] SPD Auto
x CAS# latency Auto 5T 5T
x RAS to CAS R/W Delay Auto 5T 5T
x Row Precharge Time Auto 5T 5T
x Minimum RAS Active Time Auto 18T 18T
x 1T/2T Command Timing Auto -- --
x TwTr Command Delay Auto 3T 3T
x Trfc0 for DIMM1 Auto 105ns 105ns
x Trfc2 for DIMM2 Auto -- --
x Trfc1 for DIMM3 Auto -- --
x Trfc3 for DIMM4 Auto -- --
x Write Recovery Time Auto 6T 6T
x Precharge Time Auto 3T 3T
x Row Cycle Time Auto 23T 23T
x RAS to RAS Delay Auto 3T 3T
DRAM Conguration
