BIOS Setup - 40 -
CPU Host Clock Control, CPU Frequency (MHz), Set Memory Clock, Memory Clock
The settings under the four items above are synchronous to those under the same items on the MB In-
telligent Tweaker(M.I.T.) main menu.
DCTs Mode
Allows you to set memory control mode.
Ganged Sets memory control mode to single dual-channel.
Unganged Sets memory control mode to two single-channel. (Default)
DDR3 Timing Items
Manual allows all DDR3 Timing items below to be congurable.
Options are: Auto (default), Manual.
DRAM Conguration
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
DRAMConguration
CPU Host Clock Control [Auto]
x CPU Frequency(MHz) 200
Set Memory Clock [Auto]
x Memory Clock x6.66 1333Mhz
DCTs Mode [Unganged]
DDR3 Timing Items [Auto] SPD Auto
x CAS# latency Auto 9T 9T
x RAS to CAS R/W Delay Auto 9T 9T
x Row Precharge Time Auto 9T 9T
x Minimum RAS Active Time Auto 24T 24T
x 1T/2T Command Timing Auto -- --
x TwTr Command Delay Auto 5T 5T
x Trfc0 for DIMM1 Auto 110ns 110ns
x Trfc2 for DIMM2 Auto -- --
x Trfc1 for DIMM3 Auto -- --
x Trfc3 for DIMM4 Auto -- --
x Write Recovery Time Auto 10T 10T
x Precharge Time Auto 5T 5T
x Row Cycle Time Auto 33T 33T
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
DRAMConguration
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
x RAS to RAS Delay Auto 4T 4T
CHA ProcOdt [Auto] 60 ohms
CHA DQS drive strength [Auto] 1.0x
CHA Data drive strength [Auto] 1.0x
CHA MEMCLK drive strength [Auto] 1.25x
CHA Add/Cmd drive strength [Auto] 1.5x
CHA CS/ODT drive strength [Auto] 1.5x
CHA CKE drive strength [Auto] 1.5x
CHB ProcOdt [Auto] 60 ohms
CHB DQS drive strength [Auto] 1.0x
CHB Data drive strength [Auto] 1.0x
CHB MEMCLK drive strength [Auto] 1.25x
CHB Add/Cmd drive strength [Auto] 1.5x
CHB CS/ODT drive strength [Auto] 1.5x
CHB CKE drive strength [Auto] 1.5x
Bank Interleaving [Enabled]
Channel interleave [Enabled]
