- 87 - Appendix
5-1-3 Conguring Marvell 9128 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. The Marvell 9128 SATA controller controls the GSATA3_6/7 ports on the
motherboard. Then connect the power connector from your power supply to the hard drive.
B. Conguring SATA controller and RAID mode in BIOS Setup
Make sure to congure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).
Make sure Onboard SATA3 controller under the Integrated Peripherals menu is enabled. Then set On-
board SATA3 Mode to IDE or AHCI, depending on your requirements (Figure 1). (In AHCI mode, installation
of the SATA AHCI driver is required during Windows XP installation. Refer to section, "5-1-4" for more infor-
mation.)
Step 2:
To create a RAID array, press <Enter> on the GSATA RAID Conguration item (Figure 1) to enter the RAID
conguration menu. Skip this step if you do not want to create RAID.
Figure 1
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Integrated Peripherals
OnChip IDE Channel [Enabled]
OnChip SATA Controller [Enabled]
OnChip SATA Type [RAID]
OnChip SATA Port4/5 Type [As SATA Type]
Onboard USB 3.0 Controller [Enabled]
Onboard ESATA Controller [Enabled]
Onboard ESATA Mode [RAID]
Onboard SATA3 controller [Enabled]
Onboard SATA3 Mode [IDE]
GSATARAIDConguration [PressEnter]
Onboard LAN Function [Enabled]
Onboard LAN Boot ROM [Disabled]
SMART LAN [Press Enter]
Onboard Audio Function [Enabled]
Onboard 1394 Function [Enabled]
Legacy USB storage detect [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
OnChip USB Controller [Enabled]
USB EHCI Controller [Enabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
