- 49 - BIOS Setup
AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
OnChip SATA Port4/5 Type (AMD SB750, SATA2_4~SATA2_5 connectors)
This option is congurable only when OnChip SATA Type is set to RAID or AHCI. Congures the oper-
ating mode of the integrated SATA2_4/SATA2_5 connectors.
IDE Disables RAID for the SATA controller and congures the SATA controller to PATA
mode. (Default)
As SATA Type The mode depends on the OnChip SATA Type settings.
Onboard ESATA Controller (JMicron JMB362 Chip, eSATA Connectors on the Back Panel)
Enables or disables the SATA controller integrated in the JMicron JMB362 chip. (Default: Enabled)
Onboard ESATA Mode (JMicron JMB362 Chip, eSATA Connectors on the Back Panel)
Enables or disables RAID for the SATA controller integrated in the JMicron JMB362 chip or congures
the SATA controller to AHCI mode.
IDE Disables RAID for the SATA controller and congures the SATA controller to IDE
mode.
AHCI Congures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug. (Default)
RAID Enables RAID for the SATA controller.
Onboard SATA3 controller (Marvell 9128 Chip, GSATA3_6/7 Connectors)
Enables or disables the SATA controller integrated in the Marvell 9128 chip. (Default: Enabled)
Onboard SATA3 Mode (Marvell 9128 Chip, GSATA3_6/7 Connectors)
Allows you to decide whether to congure the SATA controller integrated in the Marvell 9128 chip to
AHCI mode.
IDE Congures the SATA controller to IDE mode. (Default)
AHCI Congures the SATA controller to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
GSATA RAID Conguration (Marvell 9128 Chip, GSATA3_6/7 Connectors)
Allows you to congure RAID for the Marvell 9128 SATA controller. Refer to Chapter 5, "Conguring
SATA Hard Drive(s)," for instructions on conguring a RAID array.
Onboard LAN Function
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
