Gigabyte GA-790XTA-UD4 (rev.1) [42/120] Bank interleaving
![Gigabyte GA-790XTA-UD4 (rev.1) [42/120] Bank interleaving](/views2/1045461/page42/bg2a.png)
BIOS Setup - 42 -
********
System Voltage Optimized
********
System Voltage Control
Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the
system voltages as required. Manual allows all voltage control items below to be congurable. (Default:
Manual)
SATA3 Volt Control
Allows you to set the voltage for the Marvell 9128 chip.
Normal Supplies the voltage for the Marvell 9128 chip as required. (Default)
+0.1V ~ +0.3V The adjustable range is from +0.1V to +0.3V.
CPU PLL Voltage Control
Allows you to set the CPU PLL voltage.
Normal Supplies the CPU PLL voltage as required. (Default)
2.220V ~ 3.100V The adjustable range is from 2.220V to 3.100V.
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
CHA CKE drive strength
Options are: Auto (default), 1.0x, 1.25x, 1.5x, 2.0x.
CHB ProcOdt
Options are: Auto (default), 240 ohms, 120 ohms, 60 ohms.
CHB DQS drive strength
Options are: Auto (default), 0.75x, 1.0x, 1.25x, 1.5x.
CHB Data drive strength
Options are: Auto (default), 0.75x, 1.0x, 1.25x, 1.5x.
CHB MEMCLK drive strength
Options are: Auto (default), 0.75x, 1.0x, 1.25x, 1.5x.
CHB Add/Cmd drive strength
Options are: Auto (default), 1.0x, 1.25x, 1.5x, 2.0x.
CHB CS/ODT drive strength
Options are: Auto (default), 1.0x, 1.25x, 1.5x, 2.0x.
CHB CKE drive strength
Options are: Auto (default), 1.0x, 1.25x, 1.5x, 2.0x.
Bank Interleaving
Enables or disables memory bank interleaving. Enabled allows the system to simultaneously access dif-
ferent banks of the memory to increase memory performance and stability. (Default: Enabled)
Channel interleave
Enables or disables memory channel interleaving. Enabled allows the system to simultaneously access
different channels of the memory to increase memory performance and stability. (Default: Enabled)
