4 Configuration D-Link Smart Managed Switch User Manual

Tool Bar > Save Menu

The Save Menu provides Save Configuration and Save Log functions.

Figure 4.2 – Save Menu

Save Configuration

By clicking Apply, the current device configuration will be saved on the device’s flash memory.

Figure 4.3 – Save Configuration

Tool Bar > Tool Menu

The Tool Menu provides basic functions such as Reset, Reset System, Reboot Device, Configuration

Backup and Restore, Firmware Backup and Upgrade.

Figure 4.4 – Tool Menu

Reboot System

This option provides a safe way to reboot the system. Click Yes or No to decide to save the settings does

this really reset to factory default settings or does it just discard the most recent unsaved changes. Click

Reboot to restart the switch.

Figure 4.5 – Tool Menu > Reboot System

Reset

Provide a safe reset option for the Switch. Depending on the chosen reset option, some or all configuration

settings stored in the device’s flash memory will be reset to factory default.

Figure 4.6 – Tool Menu > Reset

Select a suitable reset option and click Apply to make the configurations take effect.

Firmware Backup and Upgrade

This functions allows you to create a backup of the device’s current firmware, or upgrade the firmware using

a compatible firmware file.
