Appendix A - Technical Specifications D-Link Smart Managed Switch User Manual
42
Appendix A - Technical Specifications
Key Components / Performance
Switching Capacity
DGS-1100-05/05PD: 10 Gbps
DGS-1100-08/08P: 16 Gbps
Max. Forwarding Rate
DGS-1100-05/05PD: 7.4 Mpps
DGS-1100-08/08P: 11.9 Mpps
Forwarding Mode
Store and Forward
Packet Buffer memory
DGS-1100-05/05PD: 1 Mb
DGS-1100-08/08P: 1.5 Mb
DRAM Size
48 KB
Flash Memory
2 MB
Port Functions
10/100/1000BASE-T
ports
5/8 10/100/1000Base-T ports compliant with the following standards:
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
Support Half/Full-Duplex operations
- IEEE 802.3x Flow control support for Full-Duplex mode
- Back Pressure for Half-Duplex mode
- Head-of-line blocking prevention
Support manual/auto-MDI/MDIX configuration.
Support auto-negotiation for each port
Physical & Environment
Dimensions
DGS-1100-05: 100.5 x 82 x 28 mm
DGS-1100-05PD: 150 x 97 x 28 mm
DGS-1100-08: 145 x 82 x 28 mm
DGS-1100-08P: 171 x 97.8 x 28.6 mm
Weights
DGS-1100-05: 0.23 kg
DGS-1100-05PD: 0.38 kg
DGS-1100-08: 0.34 kg
DGS-1100-08P: 0.433 kg
Power Supply
DGS-1100-05/08/08P: AC：100 ~ 240 V
DGS-1100-05PD: NO external power supply, PoE input only
Power Consumption
DGS-1100-05: Maximum – AC 3.42 W
Standby – AC 1.39 W
DGS-1100-05PD: Maximum – AC 23.922 W
Standby – 1.458 W
DGS-1100-08: Maximum – AC 4.94 W
Standby – AC 1.93 W
DGS-1100-08P: Maximum – AC 77.9 W
Standby – 2.0 W
