D-Link DGS-1100 Series Switch User Manual
46
Voice VLAN Port
This window is used to configure the user-defined voice traffic’s port.
To view the following window, click L2 Features > VLAN > Voice VLAN > Voice VLAN OUI, as
show below:
Figure 7-19 Voice VLAN Port window
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select the range of ports that will be used for this
configuration here.
State
Select this option to enable or disable the Voice VLAN state
of the port.
Mode Choose the Voice VLAN mode for the port. This can be Auto
untagged, Auto Tagged, or Manually configured.
Click the Apply button to accept the changes made.
