39D-Link DCS-4603 User Manual

Section 3: Conguration

Add Media

Media Name:

Snapshot:

Source:

Send pre-event

image(s) [0~3]:

Send post-

event image(s)

[0~7]:

Enter a unique name for media type you want to create.

Select this option to set the media type to snapshots.

Set the video prole to use as the media source. Refer to Video on page

34 for more information on video proles.

Set the number of pre-event images to take. Pre-event images are images

taken before the main event snapshot is taken.

Set the number of post-event images to take. Post-event images are

images taken after the main event snapshot is taken. You can set up to 7

post-event images to be taken.

For example:

If both the Send pre-event images and Send post-event images are set to

four, a total of 9 images are generated after a trigger is activated.

There are three types of media: Snapshot, Video Clip, and System Log. After making any

changes, click the Save Settings button to save your changes.

1 pic. 2 pic. 3 pic. 4 pic. 5 pic. 6 pic. 7 pic. 8 pic. 9 pic.

The moment the

trigger is activated.
