53D-Link DCS-4603 User Manual
Appendix A: Technical Specications
Technical Specications
Camera
Camera Hardware
Profile
• 1/3" 3 Megapixel progressive CMOS sensor
• Built-in Infrared-Cut Removable (ICR) Filter module
• Minimum illumination:
• Color (Day Mode): 0.5 lux
• B/W (Night Mode), IR LEDs off: 0.25 lux
• B/W (Night Mode), IR LEDs on: 0 lux
• 20 meter IR illumination distance
• Focal length: 2.8 mm
• Minimum object distance 0.2 m
• Aperture: F2.0
• 10x digital zoom
• Angle of view (16:9):
• (H) 84°
• (V) 48°
• Adjustment angle (non-motorized):
• Vertical: 340°
• Horizontal: 60°
• Rotation: 340°
Image Features • Configurable image size, quality, frame rate, and bit rate
• Time stamp and text overlays
• Configurable motion detection windows
• Configurable privacy mask zones
• Configurable shutter speed, brightness, saturation, contrast, sharpness, WDR,
and 3D filter
Video Compression • Simultaneous H.264/MJPEG format compression
• H.264/MJPEG multicast streaming
• JPEG for still images
Video Resolution • 16:9
• 1920 x 1080, 1280 x 720, 800 x 448, 640 x 360 up to 30 fps
• 4:3
• 2048 x 1536 up to 15 fps
• 1440 x 1080, 1280 x 960, 900 x 720, 800 x 592, 640 x 480 up to 30 fps
External Device
Interfaces
• 10/100 BASE-TX Fast Ethernet port • Supports 802.3af PoE (Class 2)
Network
Network Protocols • IPv6
• IPv4
• ARP
• TCP/IP
• UDP
• ICMP
• DHCP client
• NTP client (D-Link)
• DNS client
• DDNS client (D-Link)
• SMTP client
• FTP client
• HTTP/HTTPS
• Samba client
• PPPoE
• UPnP port forwarding
• RTP/RTSP/RTCP
• IP filtering
• Multicast
• CoS
• QoS/DSCP
• SNMP
• ONVIF compliant
Security • Administrator and user group protection
• Password authentication
• HTTP and RTSP authentication
