21D-Link DCS-6616 User Manual
Section 3 - Configuration
Prole 1-3:
Start/Stop
Listening:
Start/Stop
Talking:
Go To (Preset):
Select one of three predened video proles to display in the Live Video window.
Click this button to begin listening to the audio feed from a microphone connected to the camera (audio in).
Click this button to begin sending audio to speakers connected to the camera (audio out).
Selecting a preset from this list will load the preset in the Live Video windows.
