5D-Link DCS-6616 User Manual
Section 1 - Product Overview
Introduction
The DCS-6616 Speed Dome Network Camera is a professional IP surveillance solution which connect to your network
to provide high-quality live video over the Internet. The camera apparatus supports precise high-speed pan/tilt/zoom
functionality for extensive monitoring, and object tracking.
Camera Lens
Hardware Overview
Reset Button
Ethernet 10/100
RJ45 Socket
Cable Connector
Socket
