8D-Link DCS-7000L User Manual
Section 1: Product Overview
Front
Hardware Overview
1 IR LEDs
Used to illuminate the camera's eld of view at night
2 Power/Link LED
Indicates the camera's current status
3 Light Sensor
Measures the lighting conditions and switches between color and infrared
accordingly.
4 Camera Lens Records video of the surrounding area
1
4
3
2
