Wisenet SNB-6004FP [129/158] English _129
![Wisenet SNB-6004FP [129/158] English _129](/views2/1466981/page129/bg81.png)
English _129
● appenDix
Items Description
Network
Application
Programming
Interface
ONVIF Profile S
SUNAPI(HTTP API)
SVNP 1.2
Webpage Language
English, French, German, Spanish, Italian, Chinese, Korean, Russian,
Japanese, Swedish, Denish, Portuguese, Czech, Polish, Turkish,
Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Norway, Finland
Web Viewer
Supported OS : Windows XP / VISTA / 7 / 8 / 8.1, MAC OS X 10.7 ~ 10.10
Supported Browser : Microsoft Internet Explorer (Ver. 8~11)
Mozilla Firefox (Ver. 9~35), Google Chrome (Ver. 15~40),
Apple Safari (Ver. 8.0.2(Mac OS X 10.10), 7.0.6(Mac OS X 10.9), 6.0.2
(Mac OS X 10.8, 10.7 only), 5.1.7) ※ Mac OS X only
Central Management
Software
SmartViewer, SSM
Environmental
Operating Temperature
/ Humidity
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
Storage Temperature
/ Humidity
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Electrical
Input Voltage / Current AC24V, DC 12V
Power Consumption Max. 12.5W (AC 24V, 50 ~ 60Hz), Max. 10.5W (DC 12V)
Mechanical
Color / Material FRONT (BLACK) , BODY (IVORY) / FRONT(Aluminium), BODY(Plastic)
Dimension (WxHxD) W73.1 x H66.6 x D147.8mm (2.88" x 2.62" x 5.82")
Weight 385g
