English _23
● INSTALLATION & CONNECTION
Power Cable Specification for Each Model
In case of DC 12V Input:
Wire Type (AWG) #22 #20 #18
Cable Length (Max.) 20m 32m 50m
In case of AC 24V Input:
Wire Type (AWG) #22 #20 #18
Cable Length (Max.) 34m 55m 88m
Optical transmission ethernet standard
Item Contents
Ethernet : optical transmission SFP (LC Type)
Optical transmission : Ethernet physical layer 100 Base-FX, 1000 Base-X
Optical transmission : default speed 1000Mbps
Optical transmission : Ethernet standard IEEE 802.3u, IEEE 802.3z Support
Grounding the Product
Connect the ground wire to the ground terminal which is located above the power input
terminal by using a screwdriver.
J
`
Grounding protects the product from a surge or lightning.
`
When grounding, make sure to turn the product’s power off.
Recommended Grounding Cable
• Length : Less than 3M
• Gauge : 18 AWG or bigger
Ex) UL1007 AWG 18/16, UL1015 AWG18/16/14/12, UL2468 AWG18/16/14
