TX-6610

1-Port Gigabit GPON Terminal User Guide

Chapter 3. Quick Installation Guide

3.1 TCP/IP Configuration

After you directly connect your PC to the Terminal TX-6610 or connect your adapter to a

Hub/Switch which has connected to the Terminal, you need to configure your PC’s IP address. We

use the procedures in Windows 7 as an example, for other systems refer to T4 for instructions.

Step 1: Right-click Network icon(e.g. ) on the system tray, and select “Open Network and

Sharing Center > Change adapter settings”.

Step 2: Right click the icon that showed below, select Properties on the prompt page.

Figure 3-1
