TL-WPA4220
AV600 Powerline Wi-Fi Extender
37
Step 1. Press and hold the Pair button on powerline device C TL-WPA4220 for one second.
Step 2. Within two minutes, press and hold the Pair button on Powerline device A/B for one second.
Step 3. Wait until the Power LED on both adapters stops flashing and the Powerline LED becomes
solid on, and the pairing is completed.
Note:
The sequence of Step 1 and Step 2 can be exchanged.
Leave an existing Powerline Network:
As the figure above shows, powerline device A, B and C have formed a powerline network. The user
wants to remove one device (powerline adapter A) from this network.
Step 1. Press and hold the Pair button on powerline device A for about 10 seconds, and then release
the button. (All LEDs of powerline device A will momentarily go off.)
Step 2. Wait until the Powerline LED of powerline device A turns off, and the powerline adapter is
disconnected from the powerline network.
5.3 Reset
To reset the powerline device：
With the extender powered on, use a pin to press and hold the Reset button for about 5 seconds until all
LEDs go off. When the Power LED turns on and the Wi-Fi LED starts to blink rapidly, the reset process
is complete and the default settings have been restored.
Be careful, don’t power off when the device is in reset process.
