- 11 - Hardware Installation
Storage Interface GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_6, GSATA2_7) supporting up to 2
SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
USB South Bridge:
- Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets
connected to the internal USB headers)
Renesas D720200 chip:
- Up to 2 USB 3.0/2.0 ports on the back panel
IEEE 1394 T.I. TSB43AB23 chip:
- Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a brackets
connected to the internal IEEE 1394a headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x oppy disk drive connector
1 x IDE connector
6 x SATA 6Gb/s connectors
2 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
4 x USB 2.0/1.1 headers
2 x IEEE 1394a headers
1 x serial port header
1 x clearing CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
1 x optical S/PDIF Out connector
4 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x IEEE 1394a port
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker
Out/Line In/Line Out/Microphone)
