BIOS Setup - 54 -
Hardware Thermal Control
Enables or disables the CPU overheating protection function. When enabled, the CPU core voltage and
ratio will be reduced when the CPU is overheated. (Default: Enabled)
Reset Case Open Status
Keeps or clears the record of previous chassis intrusion status. Enabled clears the record of previous
chassis intrusion status and the Case Opened eld will show "No" at next boot. (Default: Disabled)
Case Opened
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header. If the system chassis cover is removed, this eld will show "Yes", otherwise it will show "No". To
clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings to
the CMOS, and then restart your system.
2-9 PC Health Status
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
PC Health Status
HardwareThermalControl [Enabled]
ResetCaseOpenStatus [Disabled]
Case Opened No
Vcore 1.392V
DDR3 1.5V 1.488V
+3.3V 3.248V
+12V 12.239V
Current System Temperature 40
o
C
Current CPU Temperature 42
o
C
Current CPU FAN Speed 2115 RPM
Current SYSTEM FAN1 Speed 0 RPM
Current SYSTEM FAN2 Speed 0 RPM
Current POWER FAN Speed 0 RPM
CPUWarningTemperature [Disabled]
CPUFANFailWarning [Disabled]
SYSTEMFAN1FailWarning [Disabled]
SYSTEMFAN2FailWarning [Disabled]
POWERFANFailWarning [Disabled]
CPUSmartFANControl [Enabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
PC Health Status
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CPUSmartFANMode [Auto]
SystemSmartFANControl [Enabled]
