- 83 - Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
Figure 1
Step 2:
Save changes and exit BIOS Setup.
5-1-2 Conguring GIGABYTE SATA2 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. See the table below for the SATA controllers and their corresponding SATA
ports. Then connect the power connector from your power supply to the hard drive.
B. Conguring SATA controller mode in BIOS Setup
Make sure to congure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).
Make sure OnChip SATA/IDE Ctrl under the Integrated Peripherals menu is enabled (Figure 1). To create
RAID, set OnChip SATA/IDE Ctrl Mode to RAID/IDE. (Default: IDE)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
OnChipSATAController [Enabled]
OnChipSATAType [NativeIDE]
x OnChip SATA Port4/5 Type IDE
x OnChipSATARAID5Support Enabled
OnChipSATA3.0Support [Enabled]
OnboardSATA/IDECtrl [Enabled]
OnboardSATA/IDECtrlMode [RAID/IDE]
OnboardLANFunction [Enabled]
OnboardLANBootROM [Disabled]
SMARTLAN [PressEnter]
OnboardAudioFunction [Enabled]
Onboard1394Function [Enabled]
OnboardUSB3.0Controller [Enabled]
USBControllers [Enabled]
USBLegacyFunction [Enabled]
USBStorageFunction [Enabled]
OnboardSerialPort1 [3F8/IRQ4]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
