- 87 - Appendix
When nished, the new RAID array will be displayed in the RAID Disk Drive List block (Figure 8).
Figure 8
ModelName RAIDLevel Capacity Status Members(HDDx)
RDD0: GRAID 0-Stripe 240 GB Normal 01
[
fg
TAB]-SwitchWindow [
hi
]-SelectITEM [ENTER]-Action [ESC]-Exit
[RAIDDiskDriveList]
[MainMenu] [HardDiskDriveList]
GigabyteTechnologyCorp.RAIDSetupUtilityv1.07.16G
Create RAID Disk Drive
Delete RAID Disk Drive
Revert HDD to Non-RAID
SolveMirrorConict
RebuildMirrorDrive
Save And Exit Setup
Exit Without Saving
Model Name Capacity Type/Status
HDD0: ST3120026AS 120 GB RAID Inside
HDD1: ST3120026AS 120 GB RAID Inside
To check more detailed information about the array, use the <Tab> key while in the Main Menu block to move
the selection bar to the RAID Disk Drive List block. Select the array and press <Enter>. A small window dis-
playing the array information will appear in the center of the screen (Figure 9).
Figure 9
ModelName RAIDLevel Capacity Status Members(HDDx)
RDD0: GRAID 0-Stripe 240 GB Normal 01
[
fg
TAB]-SwitchWindow [
hi
]-SelectRAID [ENTER]-Detail [ESC]-Exit
[RAIDDiskDriveList]
[MainMenu] [HardDiskDriveList]
GigabyteTechnologyCorp.RAIDSetupUtilityv1.07.16G
Create RAID Disk Drive
Delete RAID Disk Drive
Revert HDD to Non-RAID
SolveMirrorConict
RebuildMirrorDrive
Save And Exit Setup
Exit Without Saving
Model Name Capacity Type/Status
HDD0: ST3120026AS 120 GB RAID Inside
HDD1: ST3120026AS 120 GB RAID Inside
Name: GRAID
Level: 0-Stripe
Block: 128 KB
Capacity: 240 GB
Members: HDD01
Status: Normal
[RAIDInformation]
