Hardware Installation - 10 -
1-2 ProductSpecications
CPU AM3+ Socket:
- AMD AM3+ processor
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
5200 MT/s
Chipset
North Bridge: AMD 880G
South Bridge: AMD SB710
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1866 (O.C.)/1333/1066 MHz memory modules
* To reach DDR3 1866 MHz or above, you must install two memory modules and install
them in the DDR3_3 and DDR3_4 memory sockets.
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port, supporting a maximum resolution of 2560x1600
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
* Simultaneous output for DVI-D and HDMI is not supported.
Audio Realtek ALC889 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for Dolby
®
Home Theater
Support for S/PDIF Out
LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
2 x PCI Express x1 slots
* The PCIEX1_1 and PCIEX1_2 slots share bandwidth with the PCIEX4 slot. When the
PCIEX4 slot is populated with a x4 expansion card, the PCIEX1_1 and PCIEX1_2
slots become unavailable. If the PCIEX1_1 slot or the PCIEX1_2 slot has been
populated rst, the PCIEX4 slot will operate at up to x1.
(All PCI Express slots conform to the PCI Express 2.0 standard.)
2 x PCI slots
Multi-Graphics
Technology
Support for ATI Hybrid CrossFireX
™
technology
Storage Interface South Bridge:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD
Содержание
