![Gigabyte GA-880G-USB3 (rev. 3.1) [38/100] Dram configuration](/img/pdf.png)
Gigabyte GA-880G-USB3 (rev. 3.1) [38/100] Dram configuration
![Gigabyte GA-880G-USB3 (rev. 3.1) [38/100] Dram configuration](/views2/1047107/page38/bg26.png)
BIOS Setup - 38 -
DCTs Mode
Allows you to set memory control mode.
Ganged Sets memory control mode to single dual-channel.
Unganged Sets memory control mode to two single-channel. (Default)
DDR3 Timing Items
Manual allows all DDR3 Timing items below to be congurable.
Options are: Auto (default), Manual.
1T/2T Command Timing
Options are: Auto (default), 1T, 2T.
CAS# latency
Options are: Auto (default), 4T~12T.
RAS to CAS R/W Delay
Options are: Auto (default), 5T~12T.
Row Precharge Time
Options are: Auto (default), 5T~12T.
Minimum RAS Active Time
Options are: Auto (default), 15T~30T.
TwTr Command Delay
Options are: Auto (default), 4T~7T.
Trfc0 for DIMM1, DIMM2
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
Trfc1 for DIMM3, DIMM4
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
Write Recovery Time
Options are: Auto (default), 5T~8T, 10T, 12T.
DRAM Conguration
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
DRAMConguration
DCTsMode [Unganged]
DDR3TimingItems [Auto] SPD Auto
x 1T/2T Command Timing Auto -- --
x CAS# latency Auto 9T 6T
x RAS to CAS R/W Delay Auto 9T 6T
x Row Precharge Time Auto 9T 6T
x Minimum RAS Active Time Auto 24T 15T
x TwTr Command Delay Auto 5T 4T
x Trfc0 for DIMM1, DIMM2 Auto 90ns 90ns
x Trfc1 for DIMM3, DIMM4 Auto -- --
x Write Recovery Time Auto 10T 6T
x Precharge Time Auto 5T 4T
x Row Cycle Time Auto 33T 20T
x RAS to RAS Delay Auto 4T 4T
ChannelInterleaving [Enabled]
BankInterleaving [Enabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
