- 23 - Hardware Installation

1-8 Internal Connectors

Read the following guidelines before connecting external devices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the

power cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

13 4

1) ATX_12V

2) ATX

3) CPU_FAN

4) SYS_FAN1/SYS_FAN2

5) PWR_FAN

6) CLR_CMOS

7) SATA2_0/1/2/3/4/5

8) BAT

9) F_PANEL

10) F_AUDIO

11) SPDIF_O

12) F_USB1/F_USB2/F_USB3

13) COM
