BIOS Setup - 42 -
2-5 Advanced BIOS Features
IGX Conguration
The settings in this submenu are synchronous to those under the same items on the MB Intelligent
Tweaker(M.I.T.) main menu.
AMD C1E Support
Enables or disables the C1E CPU power-saving function in system halt state. When enabled, the power
consumption will be reduced during system halt state.
Auto If a CPU that supports hardware C1E is installed, the BIOS will automatically enable the
hardware C1E function. If not, the C1E function will be disabled. (Default)
Enabled If a CPU that supports hardware C1E is installed, the BIOS will automatically enable the
hardware C1E function. If not, the BIOS will enable the software C1E function.
Disabled Disables the C1E function.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced BIOS Features
IGXConguration [PressEnter]
AMDC1ESupport [Auto]
Virtualization [Disabled]
AMDK8Cool&Quietcontrol [Auto]
CPU Unlock
(Note)
[Disabled]
CPUcoreControl [Auto]
x CPU core 0 Enabled
x CPU core 1 Enabled
x CPU core 2
(Note)
Enabled
x CPU core 3
(Note)
Enabled
x CPU core 4
(Note)
Enabled
x CPU core 5
(Note)
Enabled
HardDiskBootPriority [PressEnter]
EFICD/DVDBootOption [Auto]
FirstBootDevice [HardDisk]
SecondBootDevice [CDROM]
ThirdBootDevice [USB-HDD]
PasswordCheck [Setup]
HDDS.M.A.R.T.Capability [Disabled]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced BIOS Features
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
AwayMode [Disabled]
FullScreenLOGOShow [Enabled]
BackupBIOSImagetoHDD [Disabled]
InitDisplayFirst [PCISlot]
(Note) This item is present only when you install a CPU that supports this feature.
