JetStream Stackable L2+/L3 Managed Switch

01Introduction

Chapter 1 Introduction

1.1 Product Overview

T2700G-28TQ/T3700G-28TQ is TP-Link’s JetStream Stackable L2+/L3 Managed Switch, supporting

up to 4 SFP+ slots. T2700G-28TQ/T3700G-28TQ is ideal for large businesses, campuses or SMB

networks requiring an outstanding, reliable and affordable 10 Gigabit solution.

T2700G-28TQ/T3700G-28TQ supports stacking of up to 8 units, thus providing flexible scalability

and protective redundancy for your networks. Moreover, aiming to better protect your network,

T2700G-28TQ/T3700G-28TQ’s main power is removable. With the help of TP-Link’s RPS,

administrators can easily change its main power if it encounters some problems without shutting

down the switch, thus enabling your network to really enjoy the benefit of uninterrupted operation.

Supporting advanced features such as OSPF, VRRP, IGMP and PIM DM/SM, T3700G-28TQ can fully

implement resilient scalable networks, and T2700G-28TQ can be upgraded with the addition of a

layer 3 license to provide these layer 3 routing features as well.

Note:

Obtain the T2700G-28TQ Layer 3 License T2700G-28TQ-L1000 via the following steps

：

■

Buy a license key from a TP-Link authorized distributor.

■

Go to T2700G-28TQ page on TP-Link website, use the license key together with the switch S/N

and the MAC address for authentication to download the license T2700G-28TQ-L1000.

1.2 Appearance

■

Front Panel

The front panel of T2700G-28TQ

T3700G-28TQ is shown as the following figure.Here we take

T3700G-28TQ as an example.

Figure 1-1 Front Panel

Console Port

LEDs

10/100/1000Mbps

RJ45 Port

Unit ID LED

SFP Port

SFP+ Port

Console Port

Designed to connect with the serial port of a computer or terminal for monitoring and configuring

the switch.
