JetStream Stackable L2+/L3 Managed Switch
03Introduction
LED Status Indication
M1,M2
On
An SFP+ transceiver/cable is connected to the corresponding port
of the Interface Card, and it is connected to a 10Gbps device, but no
activity
Flashing
A 10Gbps device is connected to the corresponding port of the
Interface Card and transmitting data
Off
No Interface Card is connected
No SFP+ transceiver/cable is connected to the installed Interface
Card
An SFP+ transceiver/cable is connected to the corresponding port
of the Interface Card, but it is not connected to a device
Port Feature
Model
10/100/1000Mbps
RJ45 Port
Console
Port
1000Mbps
SFP Port
10Gbps SFP+ Port
T2700G-28TQ 24 1 4 (Combo) 4 (2 fixed + 2 optional)
T3700G-28TQ 24 1 4 (Combo) 4 (2 fixed + 2 optional)
10/100/1000Mbps Port
Port 1-24, designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or
1000Mbps. Each has a corresponding Link/Act LED.
SFP Port
Port 21F-24F, designed to install the SFP transceiver. These four SFP transceiver slots are shared
with the associated RJ45 ports. The associated two ports are referred as a “Combo” port, which
means they cannot be used simultaneously, otherwise only RJ45 port works. The SFP ports
support 1000M SFP module connection only.
SFP+ Port
Port 25-26, designed to install the 10Gbps SFP+ transceiver or SFP+ cables. T3700G-28TQ also
provides an interface card slot on the rear panel to install the expansion card (TX432 of TP-Link
for example). If TX432 is installed, you get another two 10Gbps SFP+ ports.
Unit ID LED
Designed to display the stack Unit ID of the switch. For the switch that does not join any stack
system, it displays its default Unit ID. To modify the default unit number, please logon to the GUI
of the switch and go to Stack→Stack Management→Switch Renumber page.
