Gigabyte GA-770T-D3L (rev. 3.1) [37/100] Dram configuration

- 37 - BIOS Setup

PCIE Clock(MHz)

Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to 150 MHz.

Auto sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)

HT Link Frequency

Allows you to manually set the frequency for the HT Link between the CPU and chipset.

Auto BIOS will automatically adjust the HT Link Frequency. (Default)

200 MHz~2 GHz Sets HT Link Frequency to 200 MHz~2 GHz.

Set Memory Clock

Determines whether to manually set the memory clock. Auto lets BIOS automatically set the memory

clock as required. Manual allows the memory clock control item below to be congurable. (Default: Auto)

Memory Clock

This option is congurable only when Set Memory Clock is set to Manual.

X4.00 Sets Memory Clock to X4.00.

X5.33 Sets Memory Clock to X5.33.

X6.66 Sets Memory Clock to X6.66.

X8.00 Sets Memory Clock to X8.00.

DRAMConguration

higf

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help

F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults

Item Help

Menu Level



CPU Host Clock Control [Auto]

x CPU Frequency(MHz) 200

Set Memory Clock [Auto]

x Memory Clock x6.66 1333Mhz

DCTs Mode

(Note)

[Unganged]

DDR3 Timing Items [Auto] SPD Auto

x CAS# latency Auto 9T 9T

x RAS to CAS R/W Delay Auto 9T 9T

x Row Precharge Time Auto 9T 9T

x Minimum RAS Active Time Auto 24T 24T

x 1T/2T Command Timing Auto -- --

x TwTr Command Delay Auto 5T 5T

x Trfc0 for DIMM1 Auto 90ns 90ns

x Trfc2 for DIMM2 Auto -- --

x Write Recovery Time Auto 10T 10T

x Precharge Time Auto 5T 5T

x Row Cycle Time Auto 33T 33T

x RAS to RAS Delay Auto 4T 4T

Bank interleaving [Enabled]

DRAM Conguration

(Note) This item appears only if you install a CPU that supports this feature.
