- 39 - BIOS Setup
(Note) This item appears only if you install a CPU that supports this feature.
Trfc2 for DIMM2
Options are: Auto (default), 90ns, 110ns, 160ns, 300ns, 350ns.
Write Recovery Time
Options are: Auto (default), 5T~12T.
Precharge Time
Options are: Auto (default), 4T~7T.
Row Cycle Time
Options are: Auto (default), 11T~42T.
RAS to RAS Delay
Options are: Auto (default), 4T~7T.
Bank Interleaving
Enables or disables memory bank interleaving. Enabled allows the system to simultaneously access dif-
ferent banks of the memory to increase memory performance and stability. (Default: Enabled)
Channel interleave
Enables or disables memory channel interleaving. Enabled allows the system to simultaneously access
different channels of the memory to increase memory performance and stability. (Default: Enabled)
********
System Voltage Optimized
********
System Voltage Control
Determines whether to manually set the system voltages. Auto lets the BIOS automatically set the sys-
tem voltages as required. Manual allows all voltage control items below to be congurable. (Default: Auto)
DRAM Voltage Control
Allows you to set the memory voltage.
Normal Supplies the memory voltage as required. (Default)
1.500V ~ 2.400V The adjustable range is from 1.500V to 2.400V.
Note: Increasing memory voltage may result in damage to the memory or reduce the useful life of the
memory.
NB Voltage Control
Allows you to set the North Bridge voltage.
Normal Supplies the North Bridge voltage as required. (Default)
1.100V ~ 1.800V The adjustable range is from 1.100V to 1.800V.
CPU NB VID Control
(Note)
Allows you to set the CPU Northbridge VID voltage. Auto sets the CPU Northbridge VID voltage as re-
quired. The adjustable range is dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
CPU Voltage Control
Allows you to set the CPU voltage. Auto sets the CPU voltage as required. The adjustable range is de-
pendent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
Normal CPU Vcore
Displays the normal operating voltage of your CPU.
